Product Description
Main Features：
Adopt integrated screen. Visible in sunlight, the effect is better than the new mobile phone.
Adopt the full overlay display method. A more vivid observation of the consistency and stability of the signal.
Low strain RS mode and PIT mode operate on the same machine. Velocity, displacement, stress, velocity displacement, Case curve, split screen display, can clearly see the change of each signal.
Automatically realize click, combo, monitor mode. The deformation of the strain sensor is monitored in real time.
The fastest piling monitoring can reach 110 hammers/min.
Case analysis can be realized on site, and F-ZV curve and traveling wave curve can be displayed.
Using 24-bit high-precision low-noise ADC, ADC built-in digital filter, high signal-to-noise ratio, high reliability, low noise.
Using capacitive touch screen, no touch pen, more convenient to operate, more suitable for the operator's habit.
Data adoption, memory storage, storage method of memory card backup, massive data storage, and more secure and reliable.
Aluminum-magnesium alloy casing, imported connectors, the whole machine has higher strength and stronger anti-interference.
Built-in lithium battery DC power supply can work for more than 8 hours
On-site data is uploaded in real time through Bluetooth.
Specifications:
System | Wince operating system. A8 industrial grade core | |
System operating frequency 1G, 512M memory | ||
Sampling parameters |
Channels | 6 (high strain acceleration 2, stress 2, low strain acceleration 1 , speed 1) |
AD digits | 24 bit | |
Sampling interval | 1.6us-52428μs continuously adjustable, 0.8us step distance | |
Sample length | 1k，2k | |
Gain | X1, x2, x4, x8,auto | |
Trigger method | Channel trigger, steady state trigger | |
Bandwidth | High strain acceleration 1hz～10khz (<5%) | |
Low strain acceleration 1hz～10khz(<2%) | ||
Sampling accuracy | ±2% | |
System noise | <0.2mv(rms) | |
Time error | <0.5% | |
Amplitude nonlinearity | <10% | |
Display properties | Touch screen | Capacitive |
Size | 8.4" Optical full lamination | |
Resolution | 800x600 | |
Display mode | High-contrast compact display | |
Curve comparison | In the same frame display automatic comparison | |
Interface | Storage method | Memory storage, memory card automatic backup. |
Output interface | Dual usb, bluetooth, u disk dump. | |
Input interface | Capacitive touch screen, standard usb keyboard and mouse | |
Power supply | Built-in battery | 11.1v/7ah rechargeable lithium battery, can work continuously for more than 8 hours |
External power supply | Dc15v4a charger | |
Size | Volume and weight | 255 x 190 x 50 (mm), 1.9kg |
Working environment | Operating temperature | -10 ℃ to 50 ℃ |
Working humidity | <90% | |
