Hot Sale Geophysical Investigation HD Downholoe TV Imager Full Hole Wall Imaging System

Share to:

Hot Sale Geophysical Investigation HD Downholoe TV Imager Full Hole Wall Imaging System

The GD-C1201 hole wall imager uses a high-definition, high-resolution optical camera to ensure clear imaging and true colors.it adopts reflective axicon lens to take 360°hole wall images.

Availability:

Quantity:



Inquire Add to Basket

Model:
GD-C1201
Brand:
GOLD

Product Description

Product Description

Hot Sale Geophysical Investigation HD Downholoe TV Imager Full Hole Wall Imaging System

Product Introduction

GD-C1201 Intelligent Drillhole Optical Imager is a brand-new and superior product. It gives up the existing system structure mode that combines video capture card, controller, notebook computer and probe as well as the section manual editing mode, but adopts advanced DSP image capture and processing technology. And with highly integrated system, panorama photographing probe, real-time automatic extraction of section, clear and vivid images, automatic and accurate calibration of direction and depth, as well as all-direction and full-cylinder observation and imaging of all observation holes (vertical hole\ horizontal hole\ inclined hole\ depression or elevation hole). Therefore it is the most advanced in-hole imaging system.

Feature

* High definition imaging and recording of full borehole wall, snapshot of key positions, and measurement of borehole trajectory;

* Measuring space trajectory and actual depth of boreholes;

* Observing occurrence and development of fault crevice;

* Observing water outlet position in water-bearing fault, channeling & karst cave, and water-bearing stratum;

* Observation and quantitative analysis of strike, thickness, trend, dip angle of coal seam and ore body, and bed separation degree of dirt band between seams and roof strata.

* Measuring the thickness, width, strike, trend, and dip angle of stratum or various structures on image plane;

* Distinguishing various geologic structures like ore body, rock mass, coal seam, dirt band, and soil layer, etc.

* Especially appropriate for detection of geologic structure of coal mine roof, coal seam occurrence, fault structure in front of working face, and diversion fissure zone in overlying strata;

* Appropriate for detection of boreholes of various shapes and functions such as horizontal hole, vertical hole and inclined hole;

bolt and cable hole, gas drainage hole, oil and water drainage hole, and geological prospecting hole, etc;

Technical Specification

Model	GD-C1201
Azimuth accuracy	0.1mm
Horizontal image resolution	1024
Depth counting precision	0.01mm
Azimuth accuracy	±0.1°
CCD	1/3 inch, 700line HD no missing codes
Cable length	150m, 300m, 600m, 800m
Probe outer diameter	60mm
Practical aperture	Diameter 70-300mm
Power supply	AC220v±10% 50Hz
